NNX-2396Bi-60D & NNX-3296Bi-60D

NNX-2396Bi-60D & NNX-3296Bi-60D

SFP+ 10G, SM, BiDi, 60km

Short Description

10Gb/s SFP+ SM, BiDi, 1270nm/1330nm, 60km Optical Transceiver Module, LC

Application

  • 10GBASE-ER/LW
  • 10G Fiber Channel
  • 10G SONET/SDH, OTU2/2e
  • 10GBASE-BX

Standard

  • Compliant with MSA SFP+ specification(SFF-8431)
  • Compliant with SFF-8472
  • CPRI Line Rate Option: 9830.4Mbps,
  • Compliant to IEEE 802.3ae

The NETRO Networks SFP-10G-BXU(D)-60 is hot pluggable 3.3V Small-Form-Factor transceiver module. It designed expressly for high-speed communication applications that require rates up to 11.3Gb/s,it designed to be compliant with SFF-8472 SFP+ MSA. The module data link up to 60km in 9/125um single mode fiber.

Specification:

Absolute Maximum Ratings

Parameter

Symbol

Min

Max

Unit

Storage temperature

TS

-40

85

°C

Power Supply Voltage

Vcc

-0.5

+4

V

Relative Humidity

RH

5

95

%



Recommended Operating Conditions

Parameter

Symbol

Min

Typical

Max

Unit

Operating Case Temperature

(Commercial)

Tc

-5



70

°C

Operating Case Temperature

(Industrial)

-40



85

Power Supply Voltage

Vcc

3.13

3.3

3.47

V

Supply Current

Icc





300

mA

Data Rate





10.3125



Gbps

Fiber Length 9/125μm core SMF



60

km



Electrical Characteristics

Parameter

Symbol

Min

Typical

Max

Unit

Notes

Transmitter differential input voltage



180



850

mV



Receiver differential output Voltage



300



850

mV



Transmit Fault (TX_Fault)

Voh

2.4



Vcc+0.3

V

LVTTL

Vol

-0.3



0.4

V

LVTTL

Loss of Signal (LOS)

Voh

2.4



Vcc+0.3

V

LVTTL

Vol

-0.3



0.4

V

LVTTL

TX Disable

Vih

2



Vcc+0.3

V

LVTTL

Vil

-0.3



0.8

V

LVTTL



Optical transmitter Characteristics

Parameter

Symbol

Min

Typical

Max

Unit

Notes

Launched Power (avg.)

Pout

1

3

6

dBm



Operating Wavelength Range

λc

1320

1330

1340

nm



1260

1270

1280



Spectral Width

∆λ





1

nm

DFB

Side Mode Suppression Ratio

SMSR

30





dB



Extinction Ratio

ER

3.5





dB

2

Relative Intensity Noise

RIN





-128

dB/Hz



Optical Return Loss



12





dB



Transmitter and Dispersion Penalty

TDP





3.2

dB



Optical Tx Output disable

Pdis





-45

dBm



Output Eye Diagram

Complies with IEEE802.3ae eye masks when filtered

  • Up to 11.3 Gbps data rate
  • 1270nm DFB Tx/1330nm PIN Rx for SFP-10G-BXU-60
  • 1330nm DFB Tx/1270nm PIN Rx for SFP-10G-BXD-60
  • Simplex LC receptacle optical interface compliant
  • Single +3.3V power supply
  • Hot-pluggable
  • AC coupling of LVPECL signals
  • International Class1 laser safety certified
  • Operating temperature range:

Commercial: -5°C~70°C

Industrial: -40°C~85°C

  • RoHS Compliant
  • DDMI function available with internally calibrated mode
