1000M-SM/DF-20km
NNM-13M-20D
10/100/1000M Media Converter
Short Description
- 10/100M
- Media Converter
- Single-mode
- Dual Fiber
- 1G, 1310nm
- 20km, SC
10/100/1000M adaptive fast Ethernet optical Media Converter is a new product used for optical transmission via high-speed Ethernet. It is capable of switching between twisted pair and optical and relaying across 10/100 Base-TX/1000 Base-Fx and 1000Base-FX network segments, meeting long-distance, high-speed and high-broadband fast Ethernet workgroup users’ needs, achieving high-speed remote interconnection for up to 100 km’s relay-free computer data network. With steady and reliable performance, design in accordance with Ethernet standard and lightning protection, it is particularly applicable to a wide range of fields requiring a variety of broadband data network and high-reliability data transmission or dedicated IP data transfer network, such as telecommunication, cable television, railway, military, finance and securities, customs, civil aviation, shipping, power, water conservancy and oilfield etc, and is an ideal type of facility to build broadband campus network, cable TV and intelligent broadband FTTB/FTTH networks.
| Technical Parameters for 10/100/1000M Adaptive Fast Ethernet Optical Media Converter | |
| Number of Network Ports | 1 Channel |
| Number of Optical Ports | 1 Channel |
| NIC Transmission Rate | 10/100/1000Mbit/s |
| NIC Transmission Mode | 10/100/1000M adaptive with support for automatic inversion of MDI/MDIX |
| Optical Port Transmission Rate | 1000Mbit/s |
| Operating Voltage | AC 220V or DC +5V |
| Overall Power | <3W |
| Network Ports | RJ45 Port |
| Optical Specifications | Optical Port: SC, FC, ST (Optional) |
| Multi-Mode: 50/125, 62.5/125um | |
| Single-Mode: 8.3/125, | |
| 8.7/125um, 8/125,10/125um | |
| Wavelength: Single-Mode: 1310/1550nm | |
| Data Channel | IEEE802.3x and collision base backpressure supported |
| Working Mode: Full/half duplex supported | |
| Transmission Rate: 1000Mbit/s | |
| with error rate of zero | |
- For intranet prepared for expansion from 100M to 1000M
- For integrated data network for multimedia such as image, voice and etc.
- For point-to-point computer data transmission
- For computer data transmission network in a wide range of business application
- For broadband campus network, cable TV and intelligent FTTB/FTTH data tape
- In combination with switchboard or other computer network facilitates for: chain-type, star-type and ring-type network and other computer networks
